Tool
FPS384VS-3
Overview
Material groups
Characteristics
Technical drawing
Profile sketch
Tool data
ID | D1 | Ø d1 | Tol | P | l1 | l2 | l3 | d2 | a | ||
---|---|---|---|---|---|---|---|---|---|---|---|
166650 | M6 | 6.00 | 6HX | 1.000 | 80.0 | 17.0 | 30 | 6.00 | 4.9 | 5 | 5.55 |
Product range FPS384VS-3 M6 6HX
ID | D1 | Ø d1 | Tol | P | l1 | l2 | l3 | d2 | a | ||
---|---|---|---|---|---|---|---|---|---|---|---|
166737 | M3 | 3.00 | 6HX | 0.500 | 56.0 | 12.0 | 18 | 3.50 | 2.7 | 4 | 2.80 |
166738 | M4 | 4.00 | 6HX | 0.700 | 63.0 | 14.0 | 21 | 4.50 | 3.4 | 5 | 3.70 |
166640 | M5 | 5.00 | 6HX | 0.800 | 70.0 | 15.0 | 25 | 6.00 | 4.9 | 5 | 4.65 |
166650 | M6 | 6.00 | 6HX | 1.000 | 80.0 | 17.0 | 30 | 6.00 | 4.9 | 5 | 5.55 |
166660 | M8 | 8.00 | 6HX | 1.250 | 90.0 | 20.0 | 35 | 8.00 | 6.2 | 5 | 7.40 |
166670 | M10 | 10.00 | 6HX | 1.500 | 100.0 | 22.0 | 39 | 10.00 | 8.0 | 5 | 9.30 |
